VPL-B1153F-QK14AA VP LOW INERTIA SERVO MOTOR | Allen Bradley
Type number: VPL-B1153F-QK14AA, Part No.: VPLB1153FQK14AA, from manufacturer: Allen Bradley, Catagory: Kinetix VP Servo Motors Drives & Motors, VPL Low Inertia Motors
della101@163.com
| Module No. | VPL-B1153F-QK14AA |
| Product name | Servo Motor, Rotary, Low Inertia, IEC, 240V AC, 1024 Sin/Cos, 4000 rpm Maximum, 8.25 N-M, 1/4 Turn Right Angle Rotatable DIN Connector, Hiperface Multi-Turn |
| Product description | VPL-B1153F-QK14AA VP LOW INERTIA SERVO MOTOR | Allen Bradley |
| Part number | VPLB1153FQK14AA |
| Allen Bradley recommendation product | VPL-B1303C-CJ14AS SERVO MOTOR; KINETIX; PERMANENT MAGNET ROTARY MOTOR | Allen Bradley |
| Voltage | 230 VAC, 240 VAC, 480 VAC |
| Manufacturer | Allen Bradley |
| Country of origin | United States |
| Warranty | 1-2 year |
| Shipping Method | 1.Ship worldwide, usually 5-7 days. 2. We use DHL, FedEx, UPS,TNT |
| Remark | If you need a specific firmware or series relating to VPL-B1153F-QK14AA, please call or email us, we probably have it in our large inventory. |
