Product Description
Module No. VPL-A1001C-PJ14AS
Product name 100mm Bolt Circle Frame Size, 1 (One) Magnet Stack, 2500 RPM Rated Speed, Multi-turn Encoder, Keyed Shaft, SpeedTec Right …
Product description VPL-A1001C-PJ14AS Servo Motor, Low Inertia, 240V AC | Allen Bradley
Part number VPLA1001CPJ14AS
Allen Bradley recommendation product VPL-A1001C-PK12AA Servo Motor, Low Inertia | Allen Bradley
Voltage 230 VAC, 240 VAC, 480 VAC
Manufacturer Allen Bradley
Country of origin United States
Warranty 1-2 year
Shipping Method 1.Ship worldwide, usually 5-7 days.
2. We use DHL, FedEx, UPS,TNT
Remark If you need a specific firmware or series relating to VPL-A1001C-PJ14AS, please call or email us, we probably have it in our large inventory.
Product Catalogue

VPL-A1001C-PJ14AS Servo Motor, Low Inertia, 240V AC | Allen Bradley

Environmental     Specifications



Attribute Value
Temperature,operating 0..40℃(32…104%3
Temperature,storage 30…+40℃(-22…+104F)
Belative humidity,storag 5..90%noncondensing
Atmosphere,storage Noncorrosive
IP rating (1)of motor with optional shaft seal (2)and use of envirommentally sealed cable connectors IP66-dust tight,jet spray 4
IP rating of motor without a shaft seal,and mounted in this direction Shaft down IP53-dust tight,powerful water jets (4
Shaft horizontal P51-dust tight,water dripping vertically
Shaft up P50-dust tight.no protection from water (

(1)Intermational Protection Code (IP66)is roughly equivalent to a NEMA 35 (dust tight,drip tight).

An optional shal  sealkit is required to provide thespecified Prating for the motor.A:systerm level rating is also dependent on the IP rating of the

cable.See Additional Resources on page 23 for shaft seal installation instructions.

(3)To obtain this thermalrating,mount the motor on a surface with heat disipation equivalent to the size ofan aluminum heatsink as listed here.

Frame063mm,203.2×203.2×6.35mm(8x8x0.25in.);

Frame 075mm,254.0×254.0×6.35mm(10x10x0.25in.);

Frames 100.…165mm,3048×304.8×12.7mm(12x12x0.5in.).

(4)IPrating desoiptions are forreference only.See the intermational standards for more complete rating desoiptions.





Motor Accessories

The following accessories are available for Kinetix low-inertia servo motors.



2090-Series      Single      Motor      Cables

Factory-manufactured single motor cables are required with Kinetix VP low inertia motors.Single motor cables are deigned to effectively isolate the power,and feedback or brake signals,within the cable.Single motor cables are available in configurable standard-cable lengths,and provide

environmental and shield termination.

Contact your nearest Rockwell Automation sales office or refer to the Kinetix Motion Accesories Technical Data,publication KNXTD004,   for information about available 2090-Series single motor cables.



Shaft Seal Kits

Shaft seal kits are available,as are replacement kits for field installation.A shaft seal provides a barrier that prevents moisture and particles from entering the motor bearings.Shaft seals are made of nitrile and kits include a lubricant to reduce wear.

Shaft seals are subject to wear and require periodic inspection and replacement.Replacement is recommended every 3 months,not to exceed 12 months, depending on use.



Shaft   Seal   Kit   Catalog   Numbers



Motor Cat.No. Shaft Seal Kit Cat.No.
VPL-A063xx and VPL-B063xx VPL-SSN-F063075
VPL-A075xx and VPL-B075xx
VPL-A100xx and VPL-B100xx MPL-SSN-A3B3
VPL-A115xx and VPL-B115xx MPL-SSN-A484
VPL-A130xx and VPL-B130xx MPL-SSN-A5B5
VPI-B165X MPL-SSN-F165



See the Shaft Seal Kit Installation Instructions,publication 2090-IN012,for instructions on how to install a shaft seal.
