Product Description
| Module No. | MPL-B420F-M-X225 |
| Product name | Servo Motor, Rotary, Low Inertia, IEC, 240V AC, 1024 Sin/Cos, 4000 rpm Maximum, 8.25 N-M, 1/4 Turn Right Angle Rotatable DIN Connector, Hiperface Multi-Turn |
| Product description | MPL-B420F-M-X225 MP-Series Low-Inertia Servo Motor with Reducer | Allen Bradley |
| Part number | MPLB420FMX225 |
| Allen Bradley recommendation product | MPL-B420F-M-X226 MP-Series Low Inertia Small Frame Brushless Servo Motor | Allen Bradley |
| Voltage | 230 VAC, 240 VAC, 480 VAC |
| Manufacturer | Allen Bradley |
| Country of origin | United States |
| Warranty | 1-2 year |
| Shipping Method | 1.Ship worldwide, usually 5-7 days. 2. We use DHL, FedEx, UPS,TNT |
| Remark | If you need a specific firmware or series relating to MPL-B420F-M-X225, please call or email us, we probably have it in our large inventory. |
Product Catalogue
MPL-B420F-M-X225 MP-Series Low-Inertia Servo Motor with Reducer | Allen Bradley
| Cat. No. (1) | Frame | Ø CD mm (in.) H9 | EW(2) mm (in.) | FL(3) mm (in.) | L mm (in.) | MR mm (in.) | ZZ mm (in.) | M mm (in.) |
| LDAT-S03-CLVSM | 30 | 10.0 (0.39) | 26.0 (1.02) | 22.0 (0.87) | 13.0 (0.51) | 8.5 (0.33) | 32.5 (1.28) | M6 x 1.0 x 16 (0.04 x 0.63) |
| LDAT-S0507-CLVSM | 50 | 12.0 (0.47) | 28.0 (1.10) | 25.0 (0.98) | 16.0 (0.63) | 12.0 (0.47) | 38.0 (1.50) | |
| 70 | ||||||||
| LDAT-S1015-CLVSM | 100 | 16.0 (0.63) | 40.0 (1.57) | 32.0 (1.26) | 21.0 (0.83) | 16.0 (0.63) | 56.5 (2.22) | M8 x 1.25 x 18 (0.05 x 0.71) |
| 150 |
